Incremental optical rotary encoders with 1500 ppr can be used for robots, workbenches, injection molding machines, electronic equipment, printing and packaging machinery, non-standard equipment and CNC machine, a variety of office automation systems, industrial automation control and measurement fields.

Specification

Model Selection

Note: * denotes optional parameters, you can select parameters in drop-down lists to finish your order. Some customizable parameters can't be selected from the lists directly, please contact customer service staff for further communication.

Features

• The encoder adopts a special ASIC chip inside, which is stable and reliable in signal processing and ensures accurate output pulse.
• The overall structure is durable, long life, suitable for long time high frequency operation of industrial occasions.
• Incremental encoder has excellent anti-interference performance, can work stably in complex electromagnetic environment.
• Compact and lightweight, suitable for automation equipment with limited installation space.
• Modular design, easy installation, fast and efficient commissioning.

Dimension (unit: mm)

Application

Tips: What are the use of A and B channels?

The A- and B- channels are the inverse of the A and B channels. It means that when signal A is high, signal A- is low, and when A is low, A- is high. This usually minimizes noise. Some inputs accept both A and A- signals and then compare the two signals to help eliminate common-mode noise propagating on the wires. The received pulse can only be acknowledged if signal A is high and signal A- is low. This applies to any channel with complementary signals, signal A is only an example. This is commonly referred to as differential output.
