- Stock: In Stock
- Model: KOLAUT-JS-LS2
- Weight: 1.00
- SKU: KOLAUT-JS-LS2
Available Options
Cheap price joystick switch with 10-15A operating current, 100Ω insulation resistance, 0℃~85 ℃ Operating temperature. It has the advantages of strong shock resistance, convenient operation and long service life.
Specification
| Model | KOLAUT-LS2-2 | KOLAUT-LS2-3 |
| Product gear | 2 knob | 3 knob |
| Rated voltage | 380VAC | |
| Rated current | 10A | |
| Hole diameter | 30mm | |
| Operating current | 10-15A | |
| Insulation voltage | 600V | |
| Insulation resistance | 100MΩ | |
| Operating pressure | 5-20N | |
| Contact resistance | 200Ω | |
| Operating temperature | 0℃~85 ℃ | |
| Operation method | Emergency | |
| Installation size | 22mm | |
| Panel thickness | 2-5mm | |
| Reset method | Manual control | |
| Certificate | CCC | |
| Warranty | 12 months | |
Dimension (mm)
Tips: Classification of Joystick Switch.
1. According to the use of contact elements.
1) Snap-moving contact element.
2) Driven contact element. The contact resetting methods are all non-automatic resetting.
2. According to the protection method.
1) Open type.
2) Protected type.
3. According to the type of non-automatic control actuator.
1) Cross type handle;
2) Rotary handle type;
3) Handle type;
4) Push button type;
5) Foot pedal type;
6) Button type
